C24 — Portable Solar Power Station
2.4 kW of quiet power with 2,048 Wh of LiFePO4 storage — expandable to 10.24 kWh. Fast-charges to full in 1.5 hours, switches to UPS in under 10 ms, and is controlled from your phone.
- 2.4 kW high powerPure sine wave output, 4,800 W peak.
- 1.5 h fast chargingCharged to full in 1.5 hours from mains.
- 1.2 kW solar chargingDC 16–100 V / 25 A solar input.
- Expandable to 10.24 kWhAdd up to four expansion batteries.
- App smart controlMonitor and switch outputs remotely.
- UPS functionUnder 10 ms switchover on mains failure.
Expandable capacity — up to 10 kWh
Capacity grows by stacking expansion batteries. The base unit stays the same; only the stack height changes.
| Configuration | Capacity |
|---|---|
| C24 | 2,048 Wh |
| C24 + 1× C24 Pro | 4,096 Wh |
| C24 + 2× C24 Pro | 6,144 Wh |
| C24 + 3× C24 Pro | 8,192 Wh |
| C24 + 4× C24 Pro | 10,240 Wh |
C24
- Capacity
- 2,048 Wh
C24 + 1× C24 Pro
- Capacity
- 4,096 Wh
C24 + 2× C24 Pro
- Capacity
- 6,144 Wh
C24 + 3× C24 Pro
- Capacity
- 8,192 Wh
C24 + 4× C24 Pro
- Capacity
- 10,240 Wh
Expansion is at battery level. The P-series grows by paralleling complete units — the two mechanisms are not interchangeable.
Runtime by device
Indicative runtime from the 2,048 Wh base unit.
- Electric kettle2.6+ h700 W
- Microwave1.5+ h1,160 W
- CPAP46+ h40 W
- Drone18.4+ h100 W
- Electric grill1.1+ h1,600 W
- Mini cooler20.4+ h90 W
- Blender6.1+ h300 W
- Fan30.7+ h60 W
- Washer3.6+ h500 W
- Phone184+ h10 W
- Lamp103+ h15 W
- Laptop 13"26.3+ h70 W
Specifications
| Group | Item | Value |
|---|---|---|
| Battery | Chemistry | LiFePO4 |
| Capacity | 2,048 Wh (40 Ah / 51.2 V) | |
| Cycle life | 4,000 cycles, SOH ≥ 70% | |
| Input | Mains AC charging | AC 100–125 V / AC 174–264 V · bidirectional inverter 1,400 W max |
| Car charging | DC 12–24 V / 10 A · 240 W max | |
| Solar charging | DC 16–100 V / 25 A · 1,200 W max | |
| Output | Rated power | 2,400 W max |
| Peak power | 4,800 W max | |
| Output voltage | 110 V ±10% or 230 V ±10% | |
| Output frequency | 60 Hz ±5% or 50 Hz ±5% | |
| Waveform | Pure sine wave | |
| USB output | 2× QC18W + PD27W + PD100W max | |
| DC output | 1× cigarette lighter 12.8 V / 12 A max · 2× DC5521 12.8 V / 5 A max | |
| Function | UPS | Supported · switchover ≤ 10 ms |
| App control | Supported | |
| Battery expansion | Supported | |
| LED | 3 levels (H/M/L) + SOS | |
| General | Weight / dimensions | 23 kg / 46.5 × 26 × 29.5 cm |
| Optional accessory | C24 Pro battery pack (SGR-B200 PRO) |
Battery
- Item
- Chemistry
- Value
- LiFePO4
- Item
- Capacity
- Value
- 2,048 Wh (40 Ah / 51.2 V)
- Item
- Cycle life
- Value
- 4,000 cycles, SOH ≥ 70%
Input
- Item
- Mains AC charging
- Value
- AC 100–125 V / AC 174–264 V · bidirectional inverter 1,400 W max
- Item
- Car charging
- Value
- DC 12–24 V / 10 A · 240 W max
- Item
- Solar charging
- Value
- DC 16–100 V / 25 A · 1,200 W max
Output
- Item
- Rated power
- Value
- 2,400 W max
- Item
- Peak power
- Value
- 4,800 W max
- Item
- Output voltage
- Value
- 110 V ±10% or 230 V ±10%
- Item
- Output frequency
- Value
- 60 Hz ±5% or 50 Hz ±5%
- Item
- Waveform
- Value
- Pure sine wave
- Item
- USB output
- Value
- 2× QC18W + PD27W + PD100W max
- Item
- DC output
- Value
- 1× cigarette lighter 12.8 V / 12 A max · 2× DC5521 12.8 V / 5 A max
Function
- Item
- UPS
- Value
- Supported · switchover ≤ 10 ms
- Item
- App control
- Value
- Supported
- Item
- Battery expansion
- Value
- Supported
- Item
- LED
- Value
- 3 levels (H/M/L) + SOS
General
- Item
- Weight / dimensions
- Value
- 23 kg / 46.5 × 26 × 29.5 cm
- Item
- Optional accessory
- Value
- C24 Pro battery pack (SGR-B200 PRO)
Built and certified for export
- 10+ years lifespanLiFePO4 cells, long service life.
- 12-step inspection, 50+ test itemsEvery unit is tested before it ships.
- OEM & ODMCustomised logo printing available.
CE · FCC · RoHS · UN38.3 · MSDS · UL · market-specific certifications
Frequently asked questions
The questions buyers actually ask before a first order — answered with numbers from our own datasheets, not from a brochure.
How much power and capacity does the C24 deliver?
The C24 delivers 2,400 W continuous and 4,800 W peak from 2,048 Wh of LiFePO4 storage, with a pure sine wave. That covers tools and lighting at one workplace with no grid connection. Capacity can be extended to 10,240 Wh with C24 Pro battery packs.
Can I extend the capacity of the C24 later?
Yes. The C24 is designed for extension: with C24 Pro battery packs, usable capacity rises from 2,048 Wh to as much as 10,240 Wh. So you can start with one unit and expand only when demand actually rises, without replacing the base equipment you already bought.
How quickly is the C24 ready for use again?
On mains power the C24 is fully charged in around 1.5 hours. It also accepts up to 1.2 kW of solar charging, so a site away from the grid can run for several days without a socket. A short top-up over lunch is usually enough for the next stage of work.
What happens during a power failure?
The C24 works as a UPS substitute: switchover takes under 10 milliseconds. For connected equipment that means it keeps running through a grid failure with practically no interruption. That is the case that decides whether a tool or a control unit survives an outage.
